How to Install Hydraulic Pump Inlet Pipes Properly to Prevent Air Leaks?

Proper Installation Methods for Leak-Free hydraulic pump Inlet Pipes (Rexroth Vane pump Guide)

Users familiar with Rexroth Vane Pumps know they are commonly used as medium- to low-pressure hydraulic sources.

Proper installation and maintenance are crucial to prevent air leakage in the inlet pipe, which can lead to performance issues.

Below are key considerations for ensuring a leak-free hydraulic pump inlet pipe installation.

Requirements for Rexroth Vane Pumps

1. Speed Requirements

• Too low: The pump cannot press the vanes against the stator, preventing pressure buildup.

• Too high: May cause cavitation due to insufficient oil intake.

2. Contamination Sensitivity

• More sensitive than gear pumps; use a 30μm inlet filter to prevent debris damage.

Common Issues & Solutions for Leak-Free Inlet Pipe Installation

1. Low Oil Level → Refill the tank.

2. CLogged Inlet Pipe/Filter → Clean or replace.

3. Air Leak in Suction Chamber

• Check for cracks, loose fittings, or damaged seals.

• Replace defective pump bodies or tighten connections.

4. Stuck or Broken Vanes

• Ensure vane-to-slot clearance (0.015–0.02mm) and deburr edges.

5. Worn/Damaged Valve Plate → Resurface or replace.

6. Motor Running Backwards → Reverse rotation.

7. Excessive Oil Viscosity → Use recommended 2.5–5°E50 viscosity oil.

8. Missing/Sheared Drive Key → Reinstall or replace.

9. Overlong Inlet Pipe → Shorten for better suction.

10. Defective Pump Body (Porosity) → Replace.

11. Low Pump Speed → Adjust or replace the motor.

Low Volumetric Efficiency & Pressure Issues

1. Incorrect Vane/Rotor Assembly → Reinstall properly.

2. Excessive Vane-to-Slot Clearance → Re-machine to 0.013–0.018mm.

3. Worn Stator or Vane Tips → Flip stator 180° or replace.

4. Damaged Stator Curve → Regrind or replace.

5. Excessive Axial Clearance (＞0.07mm) → Adjust to 0.04–0.07mm.

6. Clogged Inlet → Clean filters/replace oil.

7. Faulty Oil Seal → Reinstall or replace.

8. System Leaks → Inspect pipes, fittings, and valves.
